MASW / VS30 Shear Wave Velocity Testing in Markham

Markham sits at roughly 200 meters elevation on the South Slope, where the glacial history left behind a complex mix of till plains, sand, and silt. When the 2010 Val-des-Bois quake rattled eastern Ontario, it reminded every engineer in the Greater Toronto Area that seismic design is not just a west-coast concern. We run MASW surveys across York Region because the National Building Code of Canada (NBCC) demands a site-specific VS30 value for anything beyond simple low-rise construction. A quick walk around Highway 7 or Birchmount Road shows you the patchwork of soil conditions—clay till in one lot, loose sand in the next. Guessing your site class here is a gamble no geotechnical engineer should take.

A VS30 value derived from a single borehole correlation can misclassify a Markham site by an entire NBCC class when velocity inversions are present.

Process and scope

A few years back, we were called to a site near the Rouge River where preliminary boreholes suggested stiff clay, but the developer wanted a mid-rise without the cost of deep piles. The client had already priced a conventional seismic refraction survey, but the site was hemmed in by asphalt and traffic noise that made a hammer source impractical. We deployed a 24-channel seismograph with 4.5 Hz geophones at 2-meter spacing, capturing both active shots with a sledgehammer and passive noise from nearby traffic on McCowan Road. The combined dispersion curve revealed a velocity inversion—a soft silt layer at 6 meters depth that the boreholes had barely hinted at. The VS30 came out at 210 m/s, firmly in Site Class D, which matched the NBCC Table 4.1.8.4.A classification. That single afternoon of testing saved the project from an under-designed foundation that would have risked excessive settlement during a moderate event. We often pair the surface wave data with SPT drilling to correlate Vs with N60 values, giving the structural engineer a full picture of stiffness with depth.

Local ground factors

The most common mistake we see in Markham is relying on the default NBCC assumption of Site Class C when the real profile falls into D or even E. The South Slope's glacial stratigraphy is notorious for soft silty layers sandwiched between stiffer tills, and a single CPT sounding or borehole log won't catch a velocity reversal. We reviewed a project near Markham Centre where the initial design assumed Vs30 of 350 m/s based on a handful of SPT blows. Our MASW line showed 195 m/s across the building footprint. The difference in spectral acceleration between Class C and Class D added over 20% to the base shear demand. Redesigning the lateral system after footings are poured is orders of magnitude more expensive than a half-day survey before the structural drawings are finalized.

Reference parameters

Parameter	Typical value
Geophone spacing	1 to 5 m (typical 2 m for VS30)
Geophone frequency	4.5 Hz vertical component
Channels	24 (expandable to 48)
Source (active)	10 kg sledgehammer on aluminum plate
Source (passive)	Ambient noise, traffic, machinery
Depth of investigation	30 to 50 m (site class determination)
Dispersion analysis	f-k transform and spatial autocorrelation (SPAC)

Related services

VS30 Site Classification Survey

A dedicated MASW line across the building footprint with passive noise recording. We deliver a 1D shear wave velocity profile, the calculated VS30, and the corresponding NBCC site class (A through E) with a signed engineering report for the building permit submission.

2D Shear Wave Velocity Cross-Section

For linear infrastructure or large-footprint buildings, we run multiple parallel MASW lines to map lateral velocity variations. The output is a 2D Vs section showing how stiffness changes along the alignment, useful for differential settlement analysis and locating soft zones.

Applicable standards

NBCC 2020, Division B, Article 4.1.8.4 (Site Classification for Seismic Site Response), CSA A23.3-19 (Design of Concrete Structures – seismic provisions referencing site class), ASTM D7400-19 (Standard Test Methods for Downhole Seismic Testing, cross-referenced for Vs profiling), ONTARIO REGULATION 332/12 (Building Code, referencing NBCC seismic provisions)

Frequently asked questions

What does a typical MASW survey cost for a single-family lot in Markham?

For a standard residential lot with one MASW line and VS30 reporting for building permit, the fee usually falls between CA$2,020 and CA$4,710. The range depends on access conditions, the number of passive recordings needed to reach 30 meters depth, and whether we combine it with other testing on the same mobilization.

How long does an MASW survey take on a Markham site?

Fieldwork for a single line typically takes 2 to 3 hours, including setup, multiple active shots, and at least 20 minutes of passive ambient noise recording. We usually deliver the processed VS30 profile and site class letter within 3 business days.

Do I still need a borehole if I run MASW?

MASW gives you stiffness, but not stratigraphy or moisture content. We always recommend at least one borehole or test pit to ground-truth the velocity profile. Knowing you have 200 m/s material at 8 meters is useful; knowing whether it is dense silt or clay till changes your foundation design.

Can you run MASW inside an existing building in Markham for a retrofit?

Yes, but with limitations. We use smaller geophones and a lighter impact source, and we rely more heavily on passive recording from building vibrations. The depth of investigation is usually reduced to about 20 meters, which is often sufficient for evaluating the soil directly beneath a slab-on-grade foundation.
